LC2AM-5.08-8P-140

      优势



  插拔端子,集功用、价格优势于一身；

  可与多种插座匹配,应用范围广泛；

  接线容量大，可以连接截面积为2.5mm²的柔性导线；

  插头插座防错插防错位保护；



Product Attribute
[Rated voltage(V)]	320
[Rated current(A):]	17.5
[Rated current(mm²):]	2.5
[Wire Size(AWG):]	24-12
[Single/multi-core diameter(mm²):]	0.2-2.5
[Maximum locking torque(Nm):]	0.5-0.6
[Screw:]	M3
[Strip length(mm):]	7
[Resistant voltage(kv):]	4
[Insulation Resistance:]	PA/VO
[Poles(P):]	2-24
[The same model]	MVSTBR 2.5/..-STF BLZP 5.00HC/270F SN 5ESDPM 2EDGKAM-5.0 TS5.0-C W/F MC201-E1 MVSTBR 2.5/.-STF-5.08 BLZP 5.08HC/90F 2ESDPM 2EDGKAM-5.08 TS5.08-C W/F MC201-F1
