LZ1V-5.08-21P-140



       优势



  水平型焊针,封闭型壳体,无安装螺丝；

  2-12P常备,最高可定制24P产品；

  通过防错插件对插头插座进行防错位保护。







Product Attribute
[Rated current(A)]	15A【UL】17.5A【IEC】
[Rated voltage(V)]	300V【UL】320【IEC】
[Insulation Resistance:]	PA/V0
[Poles(P):]	21p
[Terminal Block:]	pluggable terminal/PCB terminal block
[The same model]	MSTBVA 2,5/21-G-5.08 MSTBVA2.5/21-G-5.08 1755927 SL 5.08HC/21/180G 3.2SN OR BX SL5.08HC/21/180G 1147180000 SL 5.08HC/21/180G 3.2SN BK BX 1149270000 2EHDVC-21P 2EHDVC21P 2EDGVC-5.08-21P-14 2EDGVC-5.08-21P OQ-5.08-21P-180D Close OQ2154500000G OQ-C/180D-5.08-21P 21POS 5.08MM CE VRT HDR, TRM BLK 21POS5.08MMCEVRTHDR.TRMBLK 2-796636-1 2-796637-1 STLZ950/21G-5.08-V-绿色 50950215121D PTB750S-03-2-21-3 ME040-50821 F85-5-5.08-21P F855E2100051 PCB排针 8213 S / 21 G PCB排针 8213 S / 21 G OB 8213S/21GOB 25.350.5153.0

Product Attribute
[Rated current(A)]	15A【UL】17.5A【IEC】
[Rated voltage(V)]	300V【UL】320【IEC】
[Insulation Resistance:]	PA/V0
[Poles(P):]	21p
[Terminal Block:]	pluggable terminal/PCB terminal block
[The same model]	MSTBVA 2,5/21-G-5.08 MSTBVA2.5/21-G-5.08 1755927 SL 5.08HC/21/180G 3.2SN OR BX SL5.08HC/21/180G 1147180000 SL 5.08HC/21/180G 3.2SN BK BX 1149270000 2EHDVC-21P 2EHDVC21P 2EDGVC-5.08-21P-14 2EDGVC-5.08-21P OQ-5.08-21P-180D Close OQ2154500000G OQ-C/180D-5.08-21P 21POS 5.08MM CE VRT HDR, TRM BLK 21POS5.08MMCEVRTHDR.TRMBLK 2-796636-1 2-796637-1 STLZ950/21G-5.08-V-绿色 50950215121D PTB750S-03-2-21-3 ME040-50821 F85-5-5.08-21P F855E2100051 PCB排针 8213 S / 21 G PCB排针 8213 S / 21 G OB 8213S/21GOB 25.350.5153.0
