LZ1V-5.08-10P-140



       优势



  水平型焊针,封闭型壳体,无安装螺丝；

  2-12P常备,最高可定制24P产品；

  通过防错插件对插头插座进行防错位保护。







Product Attribute
[Rated current(A)]	15A【UL】17.5A【IEC】
[Rated voltage(V)]	300V【UL】320【IEC】
[Insulation Resistance:]	PA/V0
[Poles(P):]	10p
[Terminal Block:]	pluggable terminal/PCB terminal block
[The same model]	MSTBVA 2,5/10-G-5.08 MSTBVA2.5/10-G-5.08 1755817 SL 5.08HC/10/180G 3.2SN OR BX SL5.08HC/10/180G 1146910000 SL 5.08HC/10/180G 3.2SN BK BX 1148900000 2EHDVC-10P 2EHDVC10P 2EDGVC-5.08-10P-14 2EDGVC-5.08-10P OQ-5.08-10P-180D Close OQ1054500000G OQ-C/180D-5.08-10P 10POS 5.08MM CE VRT HDR, TRM BLK 10POS5.08MMCEVRTHDR.TRMBLK 1-796636-0 1-796637-0 STLZ950/10G-5.08-V-绿色 50950105121D PTB750S-03-2-10-3 ME040-50810 F85-5-5.08-10P F855E1000051 PCB排针 8213 S / 10 G PCB排针 8213 S / 10 G OB 8213S/10GOB 25.350.4053.0

Product Attribute
[Rated current(A)]	15A【UL】17.5A【IEC】
[Rated voltage(V)]	300V【UL】320【IEC】
[Insulation Resistance:]	PA/V0
[Poles(P):]	10p
[Terminal Block:]	pluggable terminal/PCB terminal block
[The same model]	MSTBVA 2,5/10-G-5.08 MSTBVA2.5/10-G-5.08 1755817 SL 5.08HC/10/180G 3.2SN OR BX SL5.08HC/10/180G 1146910000 SL 5.08HC/10/180G 3.2SN BK BX 1148900000 2EHDVC-10P 2EHDVC10P 2EDGVC-5.08-10P-14 2EDGVC-5.08-10P OQ-5.08-10P-180D Close OQ1054500000G OQ-C/180D-5.08-10P 10POS 5.08MM CE VRT HDR, TRM BLK 10POS5.08MMCEVRTHDR.TRMBLK 1-796636-0 1-796637-0 STLZ950/10G-5.08-V-绿色 50950105121D PTB750S-03-2-10-3 ME040-50810 F85-5-5.08-10P F855E1000051 PCB排针 8213 S / 10 G PCB排针 8213 S / 10 G OB 8213S/10GOB 25.350.4053.0
